Features :
1. Manual loading/ unloading Tray.

2. Tray Capacity : 20 EA.

3. Auto suction function (10 EA/time )

4. Auto pitch- shifting by stepping motor.

5. Orientation calibration station.

6. Function selection :H→V or V→H.

7. Safety device & sensor.

8. ESD required.

9. PLC control system.

10. M-M-I touch interface screen

11. Type : TO-18

12. UPH : 2.5 K

M/C Size & Weight  :
1. Overall Dimension  : 1300 x 750 x 1000 mm ( LxWxH )

2. Net Weight            : 450 kg.

Utility :

1. Power Supply         : AC110V/60 Hz, 5Amp or AC220V/50 Hz, 3Amp

2. Power Consumption:500 W
